ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 6 ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 7

Screw one clamp via a M12 screw and nut to the included

bracket. Attach the bracket using the omega locks to the

bottom of the Focus Spot Three Z. Attach and pull the safety-

cable through one of the safety holes located on the bottom

base and over the trussing system or a safe xation spot. Insert

the end in the carabine and tighten the safety screw.

NOTICE: The suitable enviromental temperature for this light-

ing xture is between -25˚ C to 45˚ C. Do not place this lighting

xture in an enviroment where the temperatures are under or

above the temperatures stated above. This will allow the xture

to run at its best and help prolong the xture life.

Focus Spot Three Z Mounting Focus Spot Three Z CAD Drawing

489mm/19.25”

284mm/11.1’

183mm/7.20”
