ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 24 ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 25

Pan Invert - Pan Inversion

1. Press the MENU button until “Pan Invert” is displayed, press

ENTER. Either “Yes” or “No” will be displayed.

2. To activate the Pan inversion press the UP or DOWN buttons

until “Yes” is displayed, press ENTER to conm. To deactivate

Pan inversion, select “No” and press Enter.

Tilt Invert - Tilt Inversion

1. Press the MENU button until “Tilt Invert” is displayed, press

ENTER. Either “Yes” or “No” will be displayed.

2. To activate the Tilt inversion press the UP or DOWN buttons

until “Yes” is displayed, press ENTER to conm. To deactivate

Tilt inversion, select “No” and press Enter.

Back Light - With this function you can make the back-

light automatically turn off after one minute.

1. Press the MENU button until “Back Light” is displayed, press

ENTER.

2. Either “On” or “O” will now be displayed. Press the UP or

DOWN buttons to select “On” to keep the backlight on at all

times, or “O” to allow the backlight to turn o after 1 minute.

Press any button to turn the backlight on again.

Manual Test - This function will let you manually test

the individual features.

1. Press the MENU button until “Manual Test” is displayed,

press ENTER.

2. Use the UP or DOWN buttons to nd the functions that you

wish to test.

3. Once you nd a function you wish to test, press the ENTER

button, the displayed value will begin to ash. You can now

adjust the values by pressing the UP and DOWN buttons. Once

you have nished testing press the ENTER button.

4. To exit the manual test mode, press the MENU button.

Auto Test - This function will run a self test program.

1. Press the MENU button until “Auto Test” is displayed, press

ENTER.

2. The xture will now run a self test. Press the MENU button to

exit.

Function Delay - With this function you can set a delay

for the reset functions in DMX mode.

1. Press the MENU button until “Function Delay” is displayed,

press ENTER.

2. Either “No Delay” or time between 1s - 3s will be displayed.

This number represents the delay setting. Use the UP and DOWN

buttons to adjust the blackout delay.

Example: If the delay is set to 3 seconds, and you go to reset the

pan/tilt motors, it will take 3 seconds for the reset to begin.

3. Press ENTER to conrm.

Zoom Mode - With this function you can adjust the

zoom.

1. Press the MENU button until “Zoom Mode” is displayed, press

ENTER.

2. The current zoom setting will be displayed.

3. Press the UP or DOWN buttons to adjust the zoom between

5M, 10M, or 15M. Press ENTER to conrm your setting.

Focus Spot Three Z System Menu Focus Spot Three Z System Menu
