ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands
4
GENERAL INFORMATION
With a brightness of 1200 NITS and a 6.0 mm pixel pitch, the AV6XS is a cost effective, bright, high-
resolution video panel designed for indoor use. Although the 3-in-1 RGB SMD2121 LEDs create an
impressive brightness of 1200 NITS, with its 0-100% adjustable brightness, the intensity of the screen
can be reduced for all indoor applications. The 6.0mm pixel pitch translates to 96 x 96 LEDs, equivalent
to 27,777 dot/m2, with a wide viewing angle of 140-degrees. Each AV6XS LED Video Panel is
composed of 4 modular LED panels, which allows for easier serviceability.
With multiple panels linked to mains power, the AV6XS LED video panel has a maximum power
consumption of 300W per panel, an average consumption of 120W per panel, and each panel is fitted
with a Locking Power Connector input and output socket allowing the power supply for multiple panels
to be linked. Locking RJ45 Ethernet Connector input and output sockets are also provided for each
panel, allowing the signal data to daisy-chain across each panel to make up a larger screen. Using
ADJ’s range of video processors with the internal 14-bit Novastar data receiving card, multiple panels
can be linked using standard Ethernet cables.
ADJ offers a number of video processors that can be used to convert a standard video signal (HDMI,
DVI, VGA etc.) for use with the AV Series LED panels. These processors range from the basic and cost
effective MCTRL-300 that can drive up to 1.3 million pixels (140 AV6XS panels,), to the advanced
Novastar VX4S that can drive up to 2.6 million pixels (280 AV6XS panels) with multiple cascades to
create unlimited size screens.
The AV6XS is a great video solution for your show, and ADJ offers full packages with video processors,
software, cabling, rigging bars and flight cases so that you have everything you need to get up and
running.
PLEASE NOTE: ADJ AV6XS LED Panel is similar in design and rigging hardware as other
ADJ AV Series LED Panel models, however the LED lumens and color may vary. Mixing
different ADJ AV Series LED Panel models together is not suggested.
