4
GENERAL INFORMATION
With a brightness of 1000 NITS and a 3.91mm pixel pitch, the AV3X is a cost effective, bright, high-resolution
video panel designed for indoor use. Although the 3-in-1 RGB SMD2121 LEDs create an impressive brightness
of 1000 NITS, with its 0-100% adjustable brightness, the intensity of the screen can be reduced for all indoor
applications. The 3.91mm pixel pitch translates to 128 x 128 LEDs, equivalent to 65,536 dot/m2, with a wide
viewing angle of 120-degrees. Each AV3X LED Video Panel is composed of 2 modular LED panels, which allows
for easier serviceability. Additionally, the AV3X LED Video Panels can connect horizontally for curved-in or curved-
out screen surfaces (convex/concave ±10°).
With multiple panels linked to mains power, the AV3X LED video panel has a maximum power
consumption of 170W per panel, an average consumption of 70W per panel, and each panel is fitted
with a Locking Power Connector input and output socket allowing the power supply for multiple panels
to be linked. Locking RJ45 Ethernet In/Out input and output sockets are also provided for each panel,
allowing the signal data to daisy-chain across each panel to make up a larger screen. Using ADJ’s
range of video processors with the internal 14-bit Novastar data receiving card, multiple panels can
be linked using standard Ethernet cables.
ADJ offers a number of video processors that can be used to convert a standard video signal (HDMI,
DVI, VGA etc.) for use with the AV Series LED panels. These processors range from the basic and cost
effective MCTRL-300 that can drive up to 1.3 million pixels (up to 79 AV3X panels,), to the advanced
Novastar VX4S that can drive up to 2.6 million pixels (up to 158 AV3X panels) with multiple cascades
to create unlimited size screens.
The AV3X is a great video solution for your show, and ADJ offers full packages with video processors,
software, cabling, rigging bars and flight cases so that you have everything you need to get up and
running.
PLEASE NOTE: ADJ AV3X LED Panel is similar in design and rigging hardware as other
ADJ AV Series LED Panel models, however the LED lumens and color may vary. Mixing
different ADJ AV Series LED Panel models together is not suggested.
