4
GENERAL INFORMATION
With a brightness of 1000 NITS and a 2.97mm pixel pitch, the AV2XS is a cost effective, bright, high-
resolution video panel designed for indoor use. Although the 3-in-1 RGB SMD2121 LEDs create an
impressive brightness of 1000 NITS, with its 0-100% adjustable brightness, the intensity of the screen
can be reduced for all indoor applications. The 2.97mm pixel pitch translates to 168 x 168 LEDs,
equivalent to 112,896 dot/m2, with a wide viewing angle of 160°. Each AV2XS LED Video Panel is
composed of 4 modular LED panels, which allows for easier serviceability. Additionally, the AV2XS LED
Video Panels can connect horizontally for curved-in or curved-out screen surfaces (convex/concave ±5°).
With multiple panels linked to mains power, the AV2XS LED video panel has a maximum power
consumption of 115W per panel, an average consumption of 35W per panel, and each panel is fitted
with a Locking Power Connector input and output socket allowing the power supply for multiple panels
to be linked. Locking RJ45 Ethernet input and output sockets are also provided for each panel,
allowing the signal data to daisy-chain across each panel to make up a larger screen. Using ADJ’s
range of video processors with the internal 14-bit NovaStar data receiving card, multiple panels can
be linked using standard Ethernet cables.
ADJ offers a number of video processors that can be used to convert a standard video signal (HDMI,
DVI, VGA etc.) for use with the AV Series LED panels. These processors range from the basic and cost
effective MCTRL-300 that can drive up to 1.3 million pixels (up to 11 AV2XS panels,), to the advanced
Novastar VX4S that can drive up to 2.6 million pixels (up to 23 AV2XS panels) with multiple cascades
to create unlimited size screens.
The AV2XS is a great video solution for your show, and ADJ offers full packages with video processors,
software, cabling, rigging bars, and flight cases so that you have everything you need to get up and
running.
PLEASE NOTE: ADJ AV2XS LED Panel is similar in design and rigging hardware as other
ADJ AV Series LED Panel models, however the LED lumens and color may vary. Mixing
different ADJ AV Series LED Panel models together is not suggested.
