ADJ Products, LLC - www.adj.com - Asteroid 1200 Instruction Manual Page 11
Asteroid 1200 Controls and Functions
1. Yolk Lock - Slide this latch down and to the left to lock the yolk into
place. Make sure to unlock the yolk before you use the unit.
2. Up Button - This button is used to scroll forwards when navigating
through the system menu.
3. Right Button - This button is used to move to the right when navi-
gating through the system menu.
4. Carrying Handles - The includes built-in carrying handles. Be sure
to always handle the unit by the built-in handles. Never lift or carry-
ing the unit by head or yoke. Pulling on or transporting the unit by the
moving head may severely damage the unit and will void the unit war-
ranty.
5. Enter Button - This button is used to select and conrm a function
in the system menu and enter the submenus.
6. Down Button - This button is used to scroll backwards when navi-
gating through the system menu.
7. Left Button - This button is used to move to the left when navigat-
ing through the system menu.
8. DC Switch - This button will allow you access to the system menu
without have the need to actually plug in the unit. Press this button for
at least 3 seconds and the display will turn on and allow you to make
changes to the system menu.
9. Digital Display - This display shows the menu and operating func-
tions that you can choose from.
10. Mode Button - This button is used to enter the main menu and
exit the submenus.
11. 3-Pin & 5-Pin XLR XLR Input Jacks - These jack’s are used to
receive an incoming DMX signal or Master/Slave signal.
12. PowerCon Output - This output is used to power cord daisy chain
two-way PowerCon cord (not included) to another Asteroid 1200 unit.
When power cord daisy chaining only connect 5 units together @ 120V
and 11 units together @ 230V. See page 54 for more information.
Asteroid 1200 Controls and Functions
13. 3-Pin & 5-Pin XLR Output Jacks - These jack’s are used to trans-
mit the incoming DMX signal to another DMX xture, or transmit a
Master/Slave signal to the next Asteroid 1200 in the chain. For best
results in DMX or Master/Slave mode terminate this jack if it is the last
unit in the chain. See “Line Termination” on page 13.
14. Ethernet Input & Output Ports - The Ethernet Input jack is used
to transmit and receive to receive an incoming Ethernet signal or Eth-
erNet Master/Slave signal. The Ethernet output jack is used to transmit
the incoming Ethernet signal to another xture, or transmit a Master/
Slave signal to the next Asteroid 1200 in the chain. See page 52 for
more information.
15. Fuse Holder - This housing stores a 7 amp protective fuse. Never
defeat the fuse, the fuse is designed to protect the electronics in the
event of severe power uctuations. Always be sure to replace the fuse
with an exact match as the one being replaced, unless otherwise told
to do so by an authorized ADJ service technician.
16. PowerCon Input - This input is used to connect the supplied Pow-
erCon cord to supply power to the unit from a matching power source.
Never use this xture if the ground prong has been removed or broken
o. The ground prong is designed to reduce the risk of re or electrical
shock in the event the unit suers from an internal short.
ADJ Products, LLC - www.adj.com - Asteroid 1200 Instruction Manual Page 10
