ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 48
ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 49
3 Sixty 2R 21 Channel DMX Mode
Channel Value Function
19 190 - 193 NO FUNCTION
194 - 255 BACKWARDS ROTATION SLOW-FAST
20 PAN/TILT MOVEMENT SPEED
0 - 225 MAX TO MIN. SPEED
226 - 235 BLACKOUT BY MOVEMENT
236 - 245 BLACKOUT BY WHEEL CHANGING
246 - 255 NO FUNCTION
21 LAMP ON/OFF, RESET & PROGRAMS
0 - 19 COLOR CHANGE NORMAL
20 - 29 COLOR CHANGE TO ANY POSITION
30 - 39 COLOR & GOBO CHANGE TO ANY
POSITION
40 - 59 LAMP ON
60 - 79 LAMP OFF
80 - 84 ALL MOTOR RESET
85 - 87 SCAN MOTOR RESET
88 - 90 COLOR MOTOR RESET
91 - 93 GOBO MOTOR RESET
94 - 96 SHUTTER/DIMMER MOTOR RESET
97 - 99 OTHER MOTOR RESET
100 - 119 INTERNAL PROGRAM 1
120 - 139 INTERNAL PROGRAM 2
140 - 159 INTERNAL PROGRAM 3
160 - 179 INTERNAL PROGRAM 4
180 - 199 INTERNAL PROGRAM 5
200 - 219 INTERNAL PROGRAM 6
220 - 239 INTERNAL PROGRAM 7
240 - 255 SOUND ACTIVE PROGRAM
The pan degree can be changed between 540° and 630°. See
page 28 to change the pan degree.
3 Sixty 2R 21 Channel DMX Mode
Channel Value Function
12 LEFT SHUTTER & STROBE
96 - 127 SHUTTER OPEN
128 - 159 PULSE EFFECT IN SEQUENCES
160 - 191 SHUTTER OPEN
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 SHUTTER OPEN
13 0 - 255 LEFT MASTER DIMMER 0% - 100%
14 RIGHT SHUTTER & STROBE
0 - 31 SHUTTER CLOSED
32 - 63 SHUTTER OPEN
64 - 95 STROBING SLOW - FAST
96 - 127 SHUTTER OPEN
128 - 159 PULSE EFFECT IN SEQUENCES
160 - 191 SHUTTER OPEN
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 SHUTTER OPEN
15 0 - 255 RIGHT MASTER DIMMER 0% - 100%
16 TILT LOCALIZATION MODEL SELECT
0 - 79 TWO TILTS MOVEMENT SEPERATELY
80 - 159 TWO TILTS WHOLE MOVEMENT
160 - 255 NO FUNCTION
17 PAN CONTINUOUS ROTATION
0 - 127 NO FUNCTION
128 - 189 FORWARDS ROTATION FAST-SLOW
190 - 193 NO FUNCTION
194 - 255 BACKWARDS ROTATION SLOW-FAST
18 LEFT TILT CONTINUOUS ROTATION
0 - 127 NO FUNCTION
128 - 189 FORWARDS ROTATION FAST-SLOW
190 - 193 NO FUNCTION
194 - 255 BACKWARDS ROTATION SLOW-FAST
19 RIGHT TILT CONTINUOUS ROTATION
0 - 127 NO FUNCTION
128 - 189 FORWARDS ROTATION FAST-SLOW
