ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 24
3 Sixty 2R System Menu
ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 25
3 Sixty 2R System Menu
tons to toggle between.
4. Press ENTER to conrm your selection or press MODE/ESC to
exit.
Lamp on via DMX (External Controller) - With this function you can
select if you want to switch the lamp on via an external controller.
This is used in conjuction with Internal Programs DMX channel, DMX
values 40-59.
1. Press the MODE/ESC button to access the main menu. Press the
UP or DOWN buttons so that “Lamp Control” is highlighted, then
press ENTER.
2. Press the UP or DOWN buttons until “Lamp On Via DMX” is dis-
played, press ENTER.
3. Either “O” or “On” will be displayed, use the UP and DOWN but-
tons to toggle between. Select “On” if you wish to activate this func-
tion, or “O” to deactivate.
4. Press ENTER to conrm your selection or press MODE/ESC to
exit.
Lamp o via DMX (External Controller) - With this function you can
select if you want to switch the lamp o via an external controller.
This is used in conjuction with Internal Programs DMX channel, DMX
values 60-79.
1. Press the MODE/ESC button to access the main menu. Press the
UP or DOWN buttons so that “Lamp Control” is highlighted, then
press ENTER.
2. Press the UP or DOWN buttons until “Lamp O Via DMX” is dis-
played, press ENTER.
3. Either “O” or “On” will be displayed, use the UP and DOWN but-
tons to toggle between. Select “On” if you wish to activate this func-
tion, or “O” to deactivate.
4. Press ENTER to conrm your selection or press MODE/ESC to
exit.
Max on at temp. - With this function you can set the inside tempera-
ture from which the lamp will restrike after automatic shut o.
1. Press the MODE/ESC button to access the main menu. Press the
UP or DOWN buttons so that “Lamp Control” is highlighted, then
press ENTER.
2. Press the UP or DOWN buttons until “Max On at Temp” is dis-
played, press ENTER.
3. “113°F” or “45°C” should now be displayed. “113°F” represents
the temperature that the lamp will restrike at. The temperature that is
recommended is 113°F.
4. Press ENTER to conrm your selection or press MODE/ESC to
exit.
Lamp o temp. - With this function you can set the inside tempera-
ture at which point the lamp will shut o.
1. Press the MODE/ESC button to access the main menu. Press the
UP or DOWN buttons so that “Lamp Control” is highlighted, then
press ENTER.
2. Press the UP or DOWN buttons until “Max On at Temp” is dis-
played, press ENTER.
3. “266°F” or “130°C” should now be displayed. “266°F” or “130°C”
represents the temperature that the lamp will automatically switch o
at. The temperature that is recommended is 266°F.
4. Press ENTER to conrm your selection or press MODE/ESC to
exit.
NOTE: When the temperature around the lamp is higher then the
preset value for longer then 5 mins, the unit will automatically
shut O the lamp. If the lamp is automatically shut o due to
over heat, it can not be restriked automatically, it must be turned
On again manually.
