Dimmer Manager software
Instruction Manual - page 8
Issue: 004
Lighting Technologies
Name of the dimmer unit
The name will show up under the unit’s icon, in various lists (left hand column on main page).
Dimmer Manager automatically creates a name with the dimmer type and the Network Address.
You can edit that name.
NETPORT XT
Select the NETPORT XT to which the dimmer unit is connected. The pull-down list shows all
known NETPORT XT. Use Adding a NETPORT XT if necessary.
If DMX fails
Decides the action taken by the dimmer unit. For full details, see The Dimmer manual "Programming
Digital Dimmers and NETBUS"
Priority
HTP: when a local cue is played, the local cue is combined with incoming DMX values, on a
HTP (Highest Takes Precedence) basis.
Priority:while a local cue is played, the DMX is faded out (fade time 5 s) and the lighting levels on
stage are as defined in the local cue.
For full details, see The Dimmer manual "Programming Digital Dimmers and NETBUS"
Configuring the DMX A - Patch
Three addressing schemes are possible:
• set a Start Address; this will give automatic sequential numbering
• selecting the non-sequential Patch; Patch to be edited with the Edit Patch function
• selecting the House Patch; House Patch to be edited with the Edit Patch function
List of dimmers in the unit
On the right: all the dimmer in the unit, with their physical number in the unit, their Dimmer Name
- adding text to a dimmer, and their power rating.
Note: If you create a virtual dimmer unit in OffLine mode, then you must define all parameters of
the virtual unit: type, dimmer rating,… See Creating a virtual dimmer.
