FUNCTIONS
Functions – HALOGEN MODE
Using the Halogen emulation mode all parameters are set to emulate the dynamics of an incandescent light, specifically
the dimmer curve and the color temperature. Lets you select five different types of incandescence:
• Halogen OFF
• Halogen Lamp 1 - 750 W
• Halogen Lamp 2 - 1000 W
• Halogen Lamp 3 - 1200 W
• Halogen Lamp 4 - 2000 W
• Halogen Lamp 5 - 2500 W
Functions – CTO MODE
Lets you select two different mode:
• Filt: The CTO parameter has effect on all the colors.
• White: The CTO parameter has effect only on White color.
Functions – GAMUT ADAPTATION
Lets you select two different mode:
• Relative
• Absolute
Functions – RGB COLOR SPACE
It defines all the possible colors that can be made from three chromaticity of Red, Green and Blu:
• Native: It is the color model defined by the primary colors of the fixture.
• sRGB: It is the standard color model used on monitors and printers.
Functions – LED FREQUENCY
Lets you select seven different base frequencies of LEDs:
• 3700 Hz
• 5600 Hz
• 9400 Hz
• 15100 Hz
• 21400 Hz
• 31000 Hz
• 33700 Hz
Functions – ZOOM DMX Disable
It let you disable (DMX slot Disable) the Zoom DMX parameter, when the parameter is deactivated is possible to set the
zoom level by the fixture’s menu (manual control option), then anytime you turn on the unit this value will be automatically
recalled. Select “DMX slot Enable” to activate the Zoom DMX parameter and control it from the desk.
