Klemantis units may be installed in a bottom, top and bottom, or top only set-up, depending on the height of the surface to be lit and on the required
e
ffect (total evenness of the light on the cyclorama or a linearly fading intensity effect).
When Klemantis units are installed in a single row (top or bottom), they create a uniform horizontal light distribution which fades vertically (see Fig. 1).
When they are installed on the floor and on the ceiling (top and bottom rows) at the same distance from the cyclorama, they create an outstandingly
u
niform vertical light distribution (see Fig. 2). Top and bottom set-up is ideal in order to achieve the most even light distribution on the cyclorama.
Figure 1
single row setup
Figure 2
top and bottom row setup
0
1000
Y, mm
2000
3
000
4
000
-1000
-
2000
-
3000
-
4000
0
X, mm
1000 2000 3000 4000 5000-1000-2000-3000-4000-5000
0
1000
Y, mm
2000
3000
4000
-1000
-2000
-3000
-4000
0
X, mm
1000 2000 3000 4000 5000-1000-2000-3000-4000-5000
6
Fig. 6
Klemantis' performance with different installation configurations
KLEMANTIS AS 1000 RGBW
9
