KLEMANTIS AS1000 - AS500
18
6. TECH DATA
4
00
(15.75")
1
000
(39.37")
1
92
(
7.56")
2
71
(
10.67")
4
00
(15.75")
192
(7.56")
271
(10.67")
500
(19.68")
KLEMANTIS AS1000 - AS500
ELECTRICAL SPECS
• Power supply: electronic auto-ranging
• Input voltage range: 110-240Vac 50/60 Hz
• Max power consumption: 280 VA at 230V/50Hz (AS1000)
• Max power consumption: 170 VA at 230V/50Hz (AS500)
POWER CONNECTION
• Power input: Neutrik PowerCON TRUE 1
• Power thru: Neutrik PowerCON TRUE 1 (daisy chain up to 5 x Klemantis
AS1000)
DATA CONNECTION
• Control protocols: DMX512 / RDM / Art-Net 4 / RDM over Art-Net 4
• Wireless control: available
• Data IN connector: 5 pins XLR + RJ45
• Data OUT connector: 5 pins XLR
MECHANICAL SPECS
• Painting: black with epoxidic powder
• Body: extruded aluminium and steel sheet
• Cooling system: automatic fan with variable speed/ LED cooling by
natural convection
• Max noise level: 24.5 dB(A) @ 1m
• IP protection rate: IP20
WEIGHT
Klemantis AS500: 11 kg
Klemantis AS1000: 16 kg
OPERATIONAL SPECS
• Working position: 45° std, rot. +/-45°
• Min. distance to illuminated surface: 0.2m
• Ambient temp. (min-max): -20°C / +40° C
• Maximum surface temperature: 90°
OPTICAL SPECS
• Source: 8/16 HCR Exclusive LED module featuring six colors: Red +
Green + Blue + Cyan + Amber + Lime
• Lifetime L
70
: 57,000 h
• Color temperature: Tunable white ranging from 2500K to 8000K, with
perfect CCT
• CRI >97 throughout the entire CCT (up to 99)
• Optics: FFL Asymmetric, proprietary optical design
• Horizontal spread: 49°
• Vertical spread: 108°
APPROVALS
• CE / ETL
PROVIDED WITH
• Neutrik PowerCON TRUE 1 power cable/bare ends (1.5m cable PVC
insulated 3X1.5mm)
• Omega bracket
