KLEMANTIS AS1000 - AS500

4.4 Control panel

Switching the fixture on - Fig. 14

The fixture comes on immediately when the power cord is plugged in.

Menu settings status

If no button is pressed, the display automatically returns to idle status after a time-out interval of about 60 seconds. Any modified value that has not yet

been confirmed with the

key will be cancelled.

Button functions – Menu SET  product overview  front panel

• If pressed in idle status: Cyclically switches between idle status and menu settings.

• If pressed while setting a menu: Moves to an upper level without changing anything (exits the function)

Decreases the value displayed (with auto-repetition), or passes to the next item on the menu

For quick access to the minimum parameter value, press the UP key while holding down the DOWN key.

Increases the value displayed (with auto-repetition), or passes to the previous item on the menu

For quick access to the maximum parameter value, press the DOWN key while holding down the UP key.

Confirms the displayed value, activates the displayed function or opens the next menu.

SELECT

DOWN

ENTER

Display inversion - Fig. 14

To activate this function press the UP

and DOWN

keys at the same time while the display is in standby.

The condition is memorized and saved for subsequent switching too. To return to the initial state, repeat the operation again.
