Dimmer Manager software
Instruction Manual - page 16
Issue: 004
Lighting Technologies
Changing the User Level when OnLine
When in on-line mode, an increase in User Level requires a user name and a password.
Example: to select User Level 3
• set Working Mode to OnLine
This opens a dialogue window “Connect…”
• type the user name: UserLevel3 (this is cAsE-sEnSiTiVe)
• click OK (no password is required)
Automatic discovery
The following simple steps will create an automatic *.dim file with an overview of the whole dimmer
system.
• set the Network Address in the dimmer units (see Setting the Network Address of the dimmer
units)
• check the correct operation of the ADN network (see Use the “Master of…” function in the
dimmers)
• insert the NETPORT XT in the ADN daisy-chain (ADN network)
• connect the NETPORT XT and the Dimmer Manager PC (via a hub/switch, or directly)
• power up dimmers, NETPORT XT, hub… (see Powering-up sequence)
• in the folder "Dimmer Manager": if there is a file default.dim, delete or rename it (e.g.
OldDefault.dim)
• start the Dimmer Manager software (see Starting the Dimmer Manager software)
This opens a blank file.
• select OnLine mode and User Level 3 (see Changing the User Level when OnLine)
Now we start the automatic "discovery" procedure, which scans the Ethernet network and generates
a list of all the NETPORT XT (and NETPORT) found, with their dimmer units.
• or Menu Bar > Dimmers > Scan dimmers or click the "Scan the network" icon
This is followed by an upload of dimmer data; this may take a minute or so for a large dimmer
system.
The programme has created a group for each NETPORT XT; each group contains the dimmer
units connected to the NETPORT XT.
• check in the left hand column that all dimmer units are shown
• choose a filename and do a "Save As"
You have now created a *.dim file with the settings of the dimmer system. We suggest that you
use this method to create a back-up file of your dimmer configuration.
Note: Data are exchanged in two steps
• preliminary data exchange with the (one or several) NETPORT XT small pop-up window:
Waiting...-Waiting for NETPORT XT answers
• data exchange with the dimmer units large pop-up window: Synchronisation- get data from
dimmers
