Dimmer Manager software
Instruction Manual - page 13
Issue: 004
Lighting Technologies
Dimmer Name - adding text to a dimmer channel
You can add a brief text description to an individual dimmer. It appears in the column "Dimmer
Name". "Test a Channel" allows you to find and test a dimmer according to its name.
To edit the Dimmer Name
• Menu Bar > Dimmers > Edit > Edit Patch
In Edit Patch, enter an alpha-numerical text in the Dimmer Name column. Max. 6 characters.
Example of a Dimmer Name: the channel number
In that case the Dimmer Name matches the numbering on the outlets in the venue, and the
channel numbering in the console. This allows special outlet numbering schemes such as the
use of Channel Numbers up to 9999 in smaller dimmer systems.
Example of a Dimmer Name: the DMX address and the DMX universe
If you copy the DMX address into the Dimmer Name, then Test a Channel will give you direct
access to that dimmer, even if you don’t know its physical location in the dimmer racks.
To Copy the DMX Addresses from the Patch column to the Dimmer Name column:
• Menu Bar > Dimmers > Edit > Edit Patch
• select all the cells with DMX addresses
• right-click Copy
• select all the target cells of the Dimmer Name column
• right-click Paste; you can insert the letter for the DMX universe, if applicable
Example of a Dimmer Name: its position or function
This example shows dimmer names inspired by position (Downstage…) or type of lamp (Fluo…).
Note about Sorting by DMX address
When dimmers are sorted by DMX address, the digits are sorted like alphanumerical characters
(not like numbers). This is because Dimmer Manager is not a spreadsheet. A simple solution is to
use the Dimmer Name field and enter the DMX addresses in a three digit format: 001 instead of
1. Sorting by Dimmer Name will then achieve the desired effect.
