EURODIM TWIN TECH
Page 87 sur 92
8.1.2 List of Errors displayed in the CTRL Board Frame
1 - “CTRL error”: explanation: there are three processors in each controller. Processor 2 or 3 is not
responding. In this case, no dimming will be possible on this controller.
2 - "Comm. error": the controller is not responding to TTD HUMAN INTERFACE (HMI) messages.
3 - “24 V error”: explanation: the 24 V power measurement inside the controller is outside the
operation range.
4 - “Temperature error”: explanation: the temperature measured in the controller is not
acceptable*.
5 - "9 V error": explanation: the 9 V power measurement inside the controller is outside the
operation range.
6 - "Control 9 V error": explanation: the control 9 V power measurement is outside the operation
range.
7 - “1V2 error: explanation: the internal 1V2 power measurement is outside the operation range.
8 - "Frequency error": explanation: the mains frequency measured at the controller input is
different from the frequency configured in the TTD HUMAN INTERFACE (HMI).
9 - “Software version error”: explanation: the software to be found on the controller (processor 1,
processor 2, processor 3) and that in the TTD HUMAN INTERFACE (HMI) Unit are not identical.
8.1.3 List of Errors displayed in the Modules Frame
• "x module(s) different"
The modules actually present in the cabinet are not those used for dimming.
Displays the number of different modules detected.
Explanation: difference between the reference column and the column present on the CONF.
POWER screen.
Press the CONF. POWER button that appears next to the error. This provides a shortcut to the
CONF. POWER menu.
Press the REF.>-PRES button in order to copy the list of modules present in the REFERENCE
column
• "Error on the x, y module(s)” (only for the Sinewave or Thyristor/Fluo modules with full-
diagnostic option)
Explanation: Operating error detected on one or more modules. Displays the number of
modules where an error has been detected.
