EURODIM TWIN TECH
Page 66 sur 92
7.9.7 Scanning the Outputs
Launch the scan by pressing the "SCAN" key. Confirm your choice.
Several stages are conducted during the scan of a circuit’s output and which can be viewed on the status
row:
− Test at 14% (of 230V) in order to detect the presence of a short circuit
(Stopping of the procedure in the event of a short-circuit).
− Dimming of the output up to 50%
− Measurement of the neutral current at 50%
Important note: The scan can only be conducted if there is no sinewave module present in the cabinet,
even if it is not selected for the scan. The sinewave modules need to be removed from
the cabinet before launching the scan
The result of the measurement appears in the "MEASUREMENT" column.
The following information can be found:
− Load value,
− No load,
− Overload,
There is an overload if:
− for a module of 3KW, a load > 4KW has been measured,
− for a module of 5KW, a load > 7KW has been measured,
The circuit currently being scanned is automatically highlighted. This function vanishes as soon as you use
the dial or select another output on the touchscreen. To find this function, press the number “6” on the
numerical keyboard.
When the load scan is completed, we can verify the differences in the table between the modules recorded
(left-hand column) and the load values measured (right-hand column). The ≠ sign appears in the central
column in the event of an inconsistency.
