EURODIM TWIN TECH
Page 16 sur 92
The user must then:
− Define or validate the control of each module’s circuits by allocating the DMX channels. See Patch,
ARTNET/sACN Patch and ARTNET/sACN Configuration menus.
− Define the laws or mode and multiplying factor applicable on each of the circuits constituting a
module with respect to the loads that are wired at each circuit’s output. These laws enable each of
the loads to be controlled correctly and risk-free (See Laws/Mult.Fact
1
. menu).
− Define the type of modules to be used in order to dim the light by accepting the list of modules
identified by the controller (see power configuration menu)
3.5 DESCRIPTION OF THE LAWS AND MODES:
The following laws are pre-recorded and available in the "Laws/Mult.Fact." menu: Linear, V120, Fluo,
Preheat, Square, Tv, BBC-TV, ON/OFF, TV2, VRT, as well as six user defined laws enabling free configuration
by the user.
The following modes are pre-recorded and available in the “Laws/Mult.Fact.” menu: DIM (Use of Dimmer
laws), SWITCH and BYPASS.
Important notes:
− The user defined laws (1 to 6) are configured by default in order to apply the Linear law.
− The six user laws are only editable via the optional RDM Dimmer manager software.
− ON/OFF law and SWITCH mode: presented in the form of a hysteresis, with a transition from 0 to 255
at 15% and transition from 255 to 0 at 12% (see switch curve).
−
3.5.1 Applications of Laws on Specific Modules
3.5.1.1 Fluo Module (TTD/F*)
The first two outputs are used for the dimmer. The law of one’s choice is applied here.
The last two outputs are used for the preheat: the switch mode shall be used.
3.5.1.2 Module DimSwitch with Dual filtering (TDD/HD*)
When the user chooses the SWITCH or BYPASS mode, the circuit is automatically configured with no
filtering.
1
Mult Fact. = Multiplication Factor or Reduction of the maximum possible output level of a dimmer circuit.
