4
Powertrain Product
MA72V07K
2.0 規格技術性能/Motor Performance
2.1 馬達/動力規格/Basic Specifications
馬達性能如表１所示，性能數據以首次測試為准，以後重複測試的數據僅作參考；
The performance of the motor is shown in Table 1. The performance data is subject
to the first test, and the data after repeated tests is for reference only;
規格表 1/Table1
Basic Specifications
型號
Model Name MB72V07K-NCE-01
馬達結構
Motor Structure Inner Rotor
馬達形式
Motor Type IPM
冷卻方式
Cooling Method
Natural Air cooling (>1.0m/s)
額定電壓
Rated Voltage [V
DC
] 72
Before GR After GR
額定轉矩
Rated Torque [Nm] 18.5 n/a
額定轉速
Rated Speed [rpm] 3,700 n/a
額定功率
Rated Output Power [kW] 7.2(9.65HP) n/a
額定相電流
Rated Phase Current (Cont.) [Ap] 92
最大轉矩
Maximum Torque [Nm] 63 n/a
最大相電流
Maximum Phase Current [Ap] 400
最大功率
Maximum Output Power [kW] 10.0(13.4HP) n/a
最大效率
Maximum Efficiency >93% n/a
最大轉速
Maximum Speed [rpm] 6,000@ β=60° n/a
保護等級
Degree of Protection IPX7
使用環境
Operation Environment -10~50°C, 65±20%RH
線圈絕緣等級
Insulation Grade Class F (155°C )
馬達位置感測器形式
Motor Position Sensor Encoder
馬達溫度訊號格式
Motor Temperature Sensor NTC
減速比
Gear Ratio NA
約略重量
Approximate Weight [kg] 16
