16
2.5.2 IPOfceDepartment/WorkgroupPoESwitch
With the business ofce expansion, the additional telephones required could be
installed in less cost via the implementation of PoE IP Telephony system than that
of the traditional circuit wiring telephony system. The PoE Ethernet Switch helps
enterprises to create an integrated data, voice, and powered network. The IEEE
802.3af compliant IP Phones can be installed without the need of an additional
power cable because the power can be provided via the standard Ethernet cable
from the connected PoE Ethernet Switch.
The Wireless AP group, PoE IP Phones and Analog Telephony Adapter work
perfectly with the PoE Ethernet Switch which injects power through the Ethernet
cables. With the PoE Ethernet Switch, IP Telephony deployment becomes more
reliable and cost effective, which helps enterprises save tremendous cost when
upgrading from the traditional telephony system to IP Telephony communications
infrastructure.
PoE
PoE
PoE
PoE
DC
802.3at Splitter
PoE VoIP
Phone
Phone
Laptop
N
N
PoE IP Camera
PoE VoIP ATA
PoE IP
Camera
Core
Switch
PoE Wireless AP
PC Group
PoE
FGSD-910HP
FGSD-910P
DC
Power Line (DC)
100Base-TX UTP
PoE
100Base-TX UTP with PoE
1000Base-T UTP
Telephone wire
Figure 2-9: IP Ofce Department / Workgroup PoE Switch Connection
