www.acti.com
Installation Guide
24
3. Insert the cables into the side hole and tightly attach the clamping nut to the conduit gland
body.
CAUTION: Make sure the clamping nut is securely attached to the conduit gland body
to avoid water leak, etc.
DISCLAIMER: The manufacturer will not be responsible for damage caused by water leak
from incorrect cabling methods.
Step 6: Install the Heavy Duty Wall Mount
Attach the heavy duty wall mount to the junction box using the four (4) screws included in the wall
mount package.
Optional: Add Extension Tube
If the heavy duty wall mount is not long enough, add one extension tube (purchased separately).
See How to Install Extension Tubes on page 28.
