ARTEX PRODUCTS / ACR ELECTRONICS, INC
DESCRIPTION, OPERATION, INSTALLATION AND MAINTENANCE MANUAL
G406-4 (453-5012)
570-5012 Rev. P Company Confidential 25-62-21 Page 58 of 70
NOTE: If verification of the digital message (i.e., 406 MHz burst) is desired, follow the
procedures outlined in SUBTASK 25-62-21-750-009 on page 33.
SUBTASK 25-62-21-450-001
B. Harness ELT Receptacle Sealing
1) Seal the harness receptacle at the ELT end to prevent moisture from penetrating the connection, thus
preventing water from beading up and causing bridging between connector pins resulting in possible
activation of the ELT. Use the following procedure:
NOTE: Perform the sealing process once all tests have been satisfactorily completed and all
harness connections have been verified to be correct.
a) Remove the mounting frame cap from the ELT.
b) Unplug the receptacle from the ELT or pull the receptacle free of the mounting frame cap, as
applicable.
c) Seal the back of the receptacle with GE RTV 162, or equivalent, such that moisture cannot
penetrate the backside of the receptacle around the terminal pins.
d) Apply Dow Corning® 4 Electrical Insulating Compound, or an equivalent meeting MIL-S-8660C,
around the receptacle pins, such that the pin area is filled with compound.
e) Plug the harness receptacle into the ELT.
f) Wipe up excess sealing compound.
g) Reinstall the mounting frame cap torqueing the thumbscrews to no more than 18 lb-in. (203
N•cm).
