5 Specifications

Electrical Parameters

Item/Tracer****AN

6210

5415

6415

8415

10415

5420

6420

8420

10420

Nominal System

Voltage

12/24VDC or Auto 12/24/36/48VDC or Auto

Battery Input

Voltage Range

8V～32V 8V～68V

Battery Type

Sealed(Default)/Gel/Flooded/User

Battery fuse

80A/58V

125A/58V

150A/58V

80A/58V

125A/58V

150A/58V

Rated charge

current

60A 50A 60A 80A 100A 50A 60A 80A 100A

Rated charge

Power

750W/12V

1500W/24V

625W/12V

1250W/24V

1875W/36V

2500W/48V

750W/12V

1500W/24V

2250W/36V

3000W/48V

1000W/12V

2000

W/24V

3000

W/36V

4000W/48V

1250W/12V

2500

W/24V

3750

W/36V

5000W/48V

625W/12V

1250W/24V

1875W/36V

2500W/48V

750W/12V

1500W/24V

2250W/36V

3000W/48V

1000W/12V

2000

W/24V

3000

W/36V

4000W/48V

1250W/12V

2500

W/24V

3750

W/36V

5000W/48V

Max. PV open

circuit voltage

100V

ʏ

92V

ʐ

150V

ʏ

138V

ʐ

200V

ʏ

180V

ʐ

MPP Voltage

Range

(Battery Voltage+2V)

～72V

ʑ

(Battery Voltage +2V)

～108V

ʑ

(Battery Voltage+2V)

～144V

ʑ

Tracking efficiency

≥

99.5%

Max. conversion

efficiency

98.0% 98.0% 98.3% 98.6% 98.5% 98.6% 98.3% 98.1% 98.5% 98.5%

Full load efficiency

97.0%

97.8%

98.0%

97.1%

97.5%

97.6%

Temperature

compensate

coefficient

－3mV/℃/2V(Default)

Self-consumption

98mA/12V;60mA/24V;50mA/36V;46mA/48V

Grounding

Common negative grounding

Relay

Rated Value:5A/30VDC; Max. Value:0.5A/60VDC

RS485 interface

RS485(5VDC/200mA,

Two RJ45 ports in parallel)

④

LCD backlight time

Default:60S,Range:0

～

999S(0S:the backlight is ON all the time)

①At minimum operating environment temperature; ②At 25℃ environment temperature;

③

The maximum PV open circuit voltage must never exceed 92V(Tracer**10AN),138V(Tracer**15AN)or180V(Tracer**20AN) at 25℃ environment temperature.

④

When connect the controller to external devices, only one of the ports can be used; when use multiple controllers in parallel, the port are for cascaded use.
