www.acopower.com
7
operation of PV array is as follows:
Condition 1:
Actual charging power of PV array ≤ Rated charging power of controller
Condition 2:
Actual charging current of PV array ≤ Rated charging current of controller
When the controller operates under “Condition 1”or“Condition 2”, it will carry out the charging
as per the actual current or power; at this time, the controller can work at the maximum power
point of PV array.
WARNING: When the power of PV module is greater than the rated charging power,
and the maximum open-circuit voltage of PV array is more than
100V(Tracer**10AN)/150V(Tracer**15AN)/200V(Tracer**20N) (at the lowest environmental
temperature), the controller may be damaged.
Condition 3:
Actual charging power of PV array＞Rated charging power of controller
Condition 4:
Actual charging current of PV array＞Rated charging current of controller
When the controller operates under “Condition 3”or“Condition 4”，it will carry out the charging
as per the rated current or power.
WARNING: When the power of PV module is greater than the rated charging power,
and the maximum open-circuit voltage of PV array is more than
100V(Tracer**10AN)/150V(Tracer**15AN)/200V(Tracer**20N) (at the lowest environmental
temperature), the controller may be damaged.
According to “Peak Sun Hours diagram”, if the power of PV array exceeds the rated charging
power of controller, then the charging time as per the rated power will be prolonged, so that
more energy can be obtained for charging the battery. However, in the practical application,
the maximum power of PV array shall not be greater than 1.5 x the rated charging power of
controller. If the maximum power of PV array exceeds the rated charging power of controller
too much, it will not only cause the waste of PV modules, but also increase the open-circuit
voltage of PV array due to the influence of environmental temperature, which may increase the
probability of damage to the controller rise. Therefore, it is very important to configure the
system reasonably. For the recommended maximum power of PV array for this controller,
please refer to the table below:
Item
Rated Charge
Current
Rated Charge
Power
Max. PV
Power
Max. PV Open
Circuit
Tracer6210AN 60A
750W/12V
1500W/24V
1125W/12V
2250W/24V
100V
①
92V
②
Tracer5415AN 50A
625W/12V
1250W/24V
1875W/36V
2500W/48V
937.5W/12V
1875W/24V
2812.5W/36V
3750W/48V
150V
①
138V
②
Tracer6415AN 60A
750W/12V
1500W/24V
1125W/12V
2250W/24V
