www.acopower.com
5
2 Installation
2.1 General Installation Notes
Before installation, please read through the entire installation instructions to get familiar with
the installation steps.
Be very careful when installing the batteries, especially flooded lead-acid battery. Please
wear eye protection, and have fresh water available to wash and clean if any contact with
battery acid.
Keep the battery away from any metal objects, which may cause short circuit of the battery.
Explosive battery gases may come out from the battery during charging, so make sure
ventilation condition is good.
Lead-acid battery are recommended, other kinds please refer to the battery manufacturer.
Ventilation is highly recommended if mounted in an enclosure. Never install the controller in
a sealed enclosure with flooded batteries! Battery fumes from vented batteries will corrode
and destroy the controller circuits.
Loose power connections and corroded wires may result in high heat that can melt wire
insulation, burning surrounding materials, or even causing fire. Ensure tight connections and
use cable clamps to secure cables and prevent them from swaying in mobile applications.
Battery connection may be wired to one battery or a bank of batteries. The following
instructions refer to a singular battery, but it is implied that the battery connection can be
made to either one battery or a group of batteries in a battery bank.
Multiple same models of controllers can be installed in parallel on the same battery bank to
achieve higher charging current. Each controller must have its own solar module(s).
Select the system cables according to 5A/mm
2
or less current density in accordance with
Article 690 of the National Electrical Code, NFPA 70.
2.2 PV Array Requirements
(1)Serial connection (string) of PV modules
As the core component of PV system, Controller could be suitable for various types of PV
modules and maximize converting solar energy into electrical energy. According to the open
circuit voltage (V
oc
) and the maximum power point voltage (V
mpp
) of the MPPT controller, the
series number of different types PV modules can be calculated. The below table is for
reference only.
Tracer6210AN:
System
voltage
36cell
Voc
＜
23V
48cell
Voc
＜
31V
54cell
Voc
＜
34V
60cell
Voc
＜
38V
MAX. Best MAX. Best MAX. Best MAX. Best
12V
4
2
2
1
2
1
2
1
24V
4
3
2
2
2
2
2
2
