English
SPECIFICATION
Find manuals and other documents for your Acer product on the official Acer support website.
*Annual energy consumption is calculated using the typical power consumption 4 hours per day, 365 days per year.
S271HL G/I S271HL H
LCD Panel
Driving System TFT Color LCD
Size 27”W (69 cm)
Pixel Pitch 0.31125 mm (H) x 0.31125 mm (V)
Brightness
300 cd/m
2
(Typical)
Contrast 100000000:1 Max (ACM)
Viewable Angle 178° (H) 178° (V) (CR=10) 170° (H) 160° (V) (CR=10)
Response Time 4 ms (G to G) 1 ms (G to G)
Panel Type VA TN
Video R, G, B Analog Interface
H-Frequency 30 KHz - 85 KHz
V-Frequency 56 - 76 Hz
Display Colors 16.7 Million
Dot Clock
VGA/DVI: 148.5 MHz
HDMI 1.4: 174.5 MHz
Maximum Resolution
VGA/DVI: 1920 x 1080 @ 60 Hz
HDMI: 1920 x 1080 @ 75 Hz
Plug & Play VESA DDCCI/DDC2B
Energy Efficiency Class B
*Annual Energy Consumption 50 (kWh) (for HDMI-Input Model)
Power Consumption (at 200 nits)
On Mode 25.8 W (Typical)
Sleep Mode 0.49 W (Typical)
Off Mode 0.36 W (Typical)
Input Connector
D-Sub
DVI-D 24 pin (Only Dual-Input Model)
HDMI 19 pin (Only HDMI-Input Model)
Input Video Signal
Analog: 0.7 Vp-p (standard), 75 OHM, Positive
Digital signal (Only Dual-Input Model)
HDMI (Only HDMI-Input Model) (Optional)
Speakers 2 W x 2 (Only Audio-Input Model) (Optional)
Maximum Screen Size
Horizontal: 597.6 mm
Vertical: 336.15 mm
Power Source
19V 2.1 A (2,1 A)
Environmental Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions 614 (W) x 424.5 (H) x 173.9 (D) mm
Weight (N. W.) 4.8 kg (net) 4.8 kg (net)
Mechanism Specifications
Tilt: -5° to +15°
Detachable foot stand: Yes (Detachable foot stand with screw release)
External Controls
Switch/Buttons
Power Button
MENU/ENTER
Input
Volume
Brightness
Mode
Functions
Brightness
Contrast
Blue Light
Black Boost
ACM On/Off
Super Sharpness
H. Position (only Analog input model)
V. Position (only Analog input model)
Focus (only Analog input model)
Clock (only Analog input model)
Auto Config (only Analog input model)
Gamma
Color Temperature
Modes
sRGB Mode
Grayscale Mode
6-axis Hue
6-axis Saturate
Volume
Mute
Over Drive
FreeSync
Aim Point
Language
OSD Timeout
Transparency
Refresh Rate Num
OSD Lock
Input
Auto Source
Hot Key Assignment
Wide Mode
DDC/CI On/Off
HDMI Black Level
Quick Start Mode
Display Information
Reset All Settings
Exit
All specifications are subject to change without notice.
