System Map: Left & Right Views
Overheating
To prevent your com-
puter from overheating
make sure nothing
blocks any vent while
the computer is in use.
Right
Left
Figure 5
Left & Right Views
1. MicroSD Card Reader
2. 2-In-1 Audio Jack
(Headphone /Microphone)
3. USB 2.0 Port
4. USB 2.0 Port
5. Security Lock Slot
6. DC-In jack
7. HDMI Port
8. USB 3.0 port
9. TYPE-C 3.0
10. Camera shutter
Combination Audio Jacks (2-In-1 Audio Jacks)
Note that the combination audio jacks can support headphones or headsets (i.e. a combination
microphone/headphone).
1. When a device is plugged in to the combination audio jack a dialog (“Which device did you
plug
in?”) box will pop-up.
2. Make sure you select the correct device from the drop-down menu corresponding to
the
device plugged-in (e.g. choose “Headset” if you have plugged-in a headset and do not
choose “Headphone” in this case), and then click OK to save the setting.
⑥ ⑦ ⑧ ⑨ ⑩
① ② ③ ④ ⑤
9
