English
SPECIFICATION
Find manuals and other documents for your Acer product on the official Acer support website.
LCD Panel
Driving System TFT Color LCD
Size 23.8”W (60 cm)
Pixel Pitch 0.2745 mm (H) x 0.2745 mm (V)
Brightness
250 cd/m
2
(Typical)
Contrast 100000000:1 Max (ACM)
Viewable Angle 178° (H) 178° (V) (CR=10)
Response Time 1 ms (VRB)
Panel Type VA
Video R, G, B Analog Interface
H-Frequency 30 - 85 KHz
V-Frequency 56 - 76 Hz
Display Colors 16.7 Million
Dot Clock 174.5 MHz
Maximum Resolution
HDMI: 1920 x 1080 @ 75 Hz
VGA: 1920 x 1080 @ 75 Hz
Plug & Play VESA DDCCI/DDC2B
Power Consumption (at 200 nits)
On Mode 22 W
Sleep Mode 0.5 W
Off Mode 0.3 W
Input Connector
D-Sub
HDMI (Only HDMI-Input Model)
Input Video Signal
Analog: 0.7 Vp-p (standard), 75 OHM, Positive
HDMI (Only HDMI-Input Model) (Optional)
Speakers 2 W x 2 (Only Audio-Input Model) (Optional)
Maximum Screen Size
Horizontal: 527.04 mm
Vertical: 296.46 mm
Power Source 100-240 V, 50/60 Hz
Environmental Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions 607 (W) x 409 (H) x 133 (D) mm
Weight (N. W.) 3.80 kg (net)
Mechanism Specifications
Tilt: -5° to +15°
Swivel: No
Height adjustment: No
Pivot: No
Detachable foot stand: Yes
External Controls
Switch/Buttons
Power Button
Hotkey 1
Hotkey 2
Input
Menu/Navi/OK
Functions
Brightness
Contrast
Blue Light
Black Boost
ACM
Super Sharpness
H. Position (only Analog input model)
V. Position (only Analog input model)
Focus (only Analog input model)
Clock (only Analog input model)
Auto Configuration (only Analog input
model)
Gamma
Color Temperature
Modes
sRGB Mode
Grayscale Mode
6-axis Hue
6-axis Saturate
Volume
Mute
Over Drive
FreeSync
Refresh Rate Num
VRB
Language
OSD Timeout
Transparency
OSD Lock
Input
Auto Source
Hot Key Assignment
Wide Mode
DDC/CI
HDMI Black Level
Quick Start Mode
Display information
Reset All Settings
Exit
Specifications vary depending on model and/or region.
