SPECIFICATION
Find manuals and other documents for your Acer product on the official Acer support website.
*Annual energy consumption is calculated using the typical power consumption 4 hours per day, 365 days per year.
LCD Panel
Driving System TFT Color LCD
Size 27”W (69 cm)
Pixel Pitch 0.233 mm (H) x 0.233 mm (V)
Brightness
350 cd/m
2
(Typical)
Contrast 100000000:1 Max (ACM)
Viewable Angle 178° (H) 178° (V) (CR=10)
Response Time 5 ms (G to G)
Panel Type In-Plane Switching
H-Frequency 31 - 90 kHz
V-Frequency 56 - 76 Hz
Display Colors 16.7 Million
Dot Clock 241.5 MHz
Maximum Resolution 2560 x 1440 @ 60 Hz
Plug & Play VESA DDCCI/DDC2B
Energy Efficiency Class A+
*Annual Energy Consumption 34 (kWh) (for HDMI-input Model)
Power Consumption (at 200 nits)
On Mode 25 W (Typical)
Sleep Mode 0.49 W (Typical)
Off Mode 0.47 W (Typical)
Input Connector
HDMI 19 pin (Only HDMI-Input Model)
DP (Only DP-Input Model)
Mini-DP (Only Mini-DP-Input Model)
Input Video Signal
HDMI signal (Only HDMI-Input Model) (Optional)
DP (Only DP-Input Model) (Optional)
Mini-DP (Only Mini-DP-Input Model) (Optional)
Speakers 2 W x 2 (Only Audio-Input Model) (Optional)
USB USB 3.0 x 4 (Optional)
Maximum Screen Size
Horizontal: 596.74 mm
Vertical: 335.66 mm
Power Source 100-240V, 50/60 Hz
Environmental Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions 614.0 (W) x 395.41 ~ 545.41 (H) x 247.17 (D) mm
Weight (N. W.) 7.93 kg (net)
Mechanism Specifications
Tilt: -5° to +35° (Only at the highest point can 35 degrees of recline be offered for
the angle of elevation)
Swivel: -60° to +60°
Height adjustment: 0 mm to 150 mm
Pivot: -90° to +90°
Detachable foot stand: Yes (Detachable foot stand with screw release)
External Controls
Switch/Buttons
Power Button
MENU/ENTER
Input
Volume
Brightness
Mode
Functions
Brightness
Contrast
Blue Light
Black Boost
ACM
Super Sharpness
Gamma
Color Temperature
Modes
sRGB Mode
Grayscale Mode
6-axis Hue
6-axis Saturate
Volume
Mute
Over Drive
Language
OSD Timeout
Transparency
OSD Lock
Input
Auto Source
DP Format
Hot Key Assignment
Wide Mode
DDC/CI
HDMI Black Level
Quick Start Mode
Power-Off USB Charge (Optional)
Display Information
Reset All Settings
Exit
Specifications vary depending on model and/or region.
