EVOLUTION GAS STEAMER

EVOLUTION Gas Steamer Start-Up Form (continued)

I accept this Start-up form as complete and accurate:

Signed: Restaurant Management

Print Name:

Date: / /

YES NO

8. What is the Lenth and Width of the Gas Supply Line L W

9. Gas Pressure measurements

Natural Gas: Static WC Dynamic WC (Dynamic should be 5WC)

Dynamic pressure should be 5”WC (Regulator valve pressure tap - 1/8NPT)

Propane: Static WC Dynamic WC (Dynamic should be 10WC)

Dynamic pressure should be 10”WC (Regulator valve pressure tap -1/8NPT)

10. What is the measured ﬂame sense on the unit? uA (microampere)

11. At what mark is the Blower Motor air shutter set to?

12. (For connected models) Is the supply water pressure lower than 30PSI (Tick Box)

13. (Connected models) With the Steam Collector Pan removed and the Steam

Chamber empty, does the Auto-Fill Water Stream hit the chamber ﬂoor half-way to

three-quarters of the way towards the opposite wall?

Note: If the Auto-Fill Water Stream is slamming against the opposite wall, then the water pressure is too

high and will need to be adjusted at the supply water shut-o valve, to the above parameters.

14. Is the Float Ball Installed in the unit?

15. Is there a High Water alarm when the Float Ball is removed?

Connected Models Only

16. Does the Low Water Light and Alarm turn OFF once the chamber water level has

reached the middle of the Low Water Sensor? (Connected Water Models will only have the

Low Water Light and no Alarm.)

17. Has additional piping been added to the steam vent? (Tick Box)

18. Does the steamer operate when all gas appliance in the kitchen are operating? (Tick

Box)

19. Verify the water temperature in COOK MODE (COO on digital display) °F

20. Does the unit cycle the heat once it is in COOK MODE? (Tick Box)

21. Is there any added drain hose/piping attached to the Steamer Drain System? Note:

Does the added drain hose/piping to the steamer meet the speciﬁcations listed on

the instruction label attached to the back of the steamer?

22. Take photographs of install, including: Front of steamer, Side view of steamer, Gas

hook up and supply.
