Installation Manual I Operation

MP4010-1809

4.5 Daily Preparation for Use - Connectionless Model

Preparing the Evolution Connection-Less model for use each

day requires very little time and eort. Simply verify that the

steamer is clean, the drain valve is in the closed position and the

cooking chamber is ﬁlled with approximately 2½ Gallons of tap

water. Close the door and push the ON/OFF key on the keypad.

The water level will need to be monitored and ﬁlled as required.

Do not use the low water warning lamp as the indicator to

check the water level as this can damage the steamer over time.

PREHEATING

1. Depress the ON/OFF Key to turn on the steamer. The

display will indicate PrE.

2. Once the steamer is preheated and ready to cook, the

display will indicate COO (Cook Mode) or HLd (Hold Mode).

3. Depress the DISP TEMP button to display the current

cooking chamber temperature. MAX temperature at sea

level in 212°F

COOKING

1. Depress the COOK/HOLD button to select the Cook Mode

(COO).

2. Open the door and place food into the cooking chamber.

Shut the door.

Cooking begins immediately.

3. Timer — Depress the TIMER button and depress the

ARROW keys until the desired time is displayed. The

timer starts automatically. At the end of the timed cycle, a

beeper will sound.

4. Depress the DISP TEMP button to display the current

cooking chamber temperature.

HOLDING

In “Hold” the steamer temperature is set for 180°F

from the factory. The hold temperature can be changed to a

single value for temperatures ranging from 150° F to 190° F if

required. Contact the AccuTemp Technical Service Department

for assistance at 800.480.0415. Hold can also be used during

downtimes to save energy and water while keeping the steamer

preheated.

1. Depress the COOK/HOLD button to select the Hold Mode

(HLd).

2. Open the door and place food into the cooking chamber.

Shut the door.

3. Food will be held at the preset holding temperature. The

factory default setting is set at 180° F.

4. Depress the DISP TEMP button to display the current

cooking chamber temperature.

4.6 Cleaning

Do not use a water jet or pressure washer to clean the

steamer.

After cleaning procedure is complete, steamer door must

be left open to allow steamer to dry. Not doing so will decrese

life of door gasket.

If local water conditions cause rust inside the steamer or

heavy mineral buildup, request the AccuTemp Additional Clean-

ing Recommendations.

4.6.1 Daily Cleaning - Connected

1. Close the drain valve and add 1 cup (8 ounces or 0.24

liters) of white vinegar to the cooking compartment.

Start the steamer in the Cook Mode. The cooking

compartment will automatically ﬁll with water. After 15

minutes, turn the steamer o and allow the steamer

to cool to 140°F or lower. Then open the drain valve

and allow the water in the cooking chamber to drain

completely.

2. Turn the steamer o and wait for the steamer to cool below

100° F

3. Open the drain valve and allow the cooking compartment

to drain completely. Remove the pan racks, steam collector,

overﬁll sensor and condensate tray for cleaning. Wipe the

inside of the cooking chamber, pan rails, steam collector,

overﬁll sensor, and condensate tray with a clean cloth

(FIGURE 19). Clean the door gasket, inside of door and front

face of the cooking chamber. Clean water sensors with a

non metallic cleaning pad.

4. Re-install the overﬁll sensor, steam collector, pan rails and

condensate tray. Leave the door open overnight.

(NOTE: The steamer will not operate without the overﬁll

sensor. An alarm will also sound).

4.6.2 Daily Cleaning - Connectionless

1. Close the drain valve and add 1 cup (8 ounces or 0.24

liters) of white vinegar to the cooking compartment.

Start the steamer in the Cook Mode. The cooking

compartment will automatically ﬁll with water. After 15

minutes, turn the steamer o and allow the steamer

to cool to 140°F or lower. Then open the drain valve

and allow the water in the cooking chamber to drain

completely.

2. Turn the steamer o and wait for the steamer to cool.

3. Open the drain valve and allow the cooking chamber

to drain completely. Remove the pan rails (FIGURE 19)

and steam collector. Wipe the inside of the cooking

chamber, water sensors, pan rails and steam collector with

a clean cloth. Clean the door gasket, inside of door and

front face of the cooking chamber.

4. Install the steam collector and pan rails. Once the

water in the drain pan has suciently cooled empty the

drain pan wipe down and replace. Leave the door open

overnight.
