Installation Manual I Operation

MP4053-2006

4.5 Daily Preparation for Use - Connectionless Model

Preparing the Evolution Connection-Less model for use each

day requires very little time and eort. Simply verify that the

steamer is clean, the drain valve is in the closed position and the

cooking chamber is ﬁlled with approximately 2½ Gallons of tap

water. Close the door and push the ON/OFF key on the keypad.

The water level will need to be monitored and ﬁlled as required.

Do not use the low water warning lamp as the indicator to

check the water level as this can damage the steamer over time.

PREHEATING

1. Depress the ON/OFF Key to turn on the steamer. The

display will indicate PrE.

2. Once the steamer is preheated and ready to cook, the

display will indicate COO (Cook Mode) or HLd (Hold Mode).

3. Depress the DISP TEMP button to display the current

cooking chamber temperature. MAX temperature at sea

level in 212°F

COOKING

1. Depress the COOK/HOLD button to select the Cook Mode

(COO).

2. Open the door and place food into the cooking chamber.

Shut the door.

Cooking begins immediately.

3. Timer — Depress the TIMER button and depress the

ARROW keys until the desired time is displayed. The

timer starts automatically. At the end of the timed cycle, a

beeper will sound.

4. Depress the DISP TEMP button to display the current

cooking chamber temperature.

HOLDING

In “Hold” the steamer temperature is set for 180°F

from the factory. The hold temperature can be changed to a

single value for temperatures ranging from 150° F to 190° F if

required. Contact the AccuTemp Technical Service Department

for assistance at 800.480.0415. Hold can also be used during

downtimes to save energy and water while keeping the steamer

preheated.

1. Depress the COOK/HOLD button to select the Hold Mode

(HLd).

2. Open the door and place food into the cooking chamber.

Shut the door.

3. Food will be held at the preset holding temperature. The

factory default setting is set at 180° F.

4. Depress the DISP TEMP button to display the current

cooking chamber temperature.

4.6 Power Plate Setting

If using a Connection-less unit, do not adjust the power

plate in the unit. It will aect the water evaporation ratio

and cause the unit to be ﬁlled more regularly

The Power Plate has 3 settings (FIGURE 4.D):

• Batch - Factory Setting - Slowest Cook

• A la Carte

• Power Steam - Fastest Cook

Instructions to Adjust:

Tools Required

7/16” wrench or 7/16” socket wrench or adjustable wrench

Batch

1. Leave as received from the factory.

A la Carte

1. Remove the acorn nut and lock washer.

2. Remove the Power Plate and ﬂip it so the larger size hole is

lined up over the large vent hole.

3. Slide the Power Plate onto the stud and install the lock

washer then the acorn nut and tighten.

Power Steam

1. Remove the acorn nut and lock washer.

2. Remove the power plate from the mounting stud.

3. Rotate plate so that the large rear vent is not covered by

the plate.

4. Slide onto the stud and install the lock washer then the

acorn nut and tighten.

ACCUTEMP EVOLUTION POWER PLATE

The Power Plate has 3 settings:

Batch - Factory Setting•

A la Carte•

Power Steam•

INSTRUCTIONS

Tools Required

7/16” wrench or 7/16” socket wrench or adjustable wrench

Batch

Leave as received from the factory.

A la Carte

Remove the acorn nut and lock washer.

Remove the Power Plate and ip it so the larger size hole is lined up over the large vent hole.

Slide the Power Plate onto the stud and install the lock washer then the acorn nut and tighten.

Power Steam

Remove the acorn nut and lock washer.

Remove the power plate from the mounting stud.

Rotate plate so that the large rear vent is not covered by the plate.

Slide onto the stud and install the lock washer then the acorn nut and tighten.

Batch

A la Carte

Power Steam

ACCUTEMP EVOLUTION POWER PLATE

The Power Plate has 3 settings:

Batch - Factory Setting•

A la Carte•

Power Steam•

INSTRUCTIONS

Tools Required

7/16” wrench or 7/16” socket wrench or adjustable wrench

Batch

Leave as received from the factory.

A la Carte

Remove the acorn nut and lock washer.

Remove the Power Plate and ip it so the larger size hole is lined up over the large vent hole.

Slide the Power Plate onto the stud and install the lock washer then the acorn nut and tighten.

Power Steam

Remove the acorn nut and lock washer.

Remove the power plate from the mounting stud.

Rotate plate so that the large rear vent is not covered by the plate.

Slide onto the stud and install the lock washer then the acorn nut and tighten.

Batch

A la Carte

Power Steam

ACCUTEMP EVOLUTION POWER PLATE

The Power Plate has 3 settings:

Batch - Factory Setting•

A la Carte•

Power Steam•

INSTRUCTIONS

Tools Required

7/16” wrench or 7/16” socket wrench or adjustable wrench

Batch

Leave as received from the factory.

A la Carte

Remove the acorn nut and lock washer.

Remove the Power Plate and ip it so the larger size hole is lined up over the large vent hole.

Slide the Power Plate onto the stud and install the lock washer then the acorn nut and tighten.

Power Steam

Remove the acorn nut and lock washer.

Remove the power plate from the mounting stud.

Rotate plate so that the large rear vent is not covered by the plate.

Slide onto the stud and install the lock washer then the acorn nut and tighten.

Batch

A la Carte

Power Steam

Batch

A la Carte

Power Steam

FIGURE 4.D
