6
Reversing the Door
Unless ordered as the LHD option, your unit comes with a right-hand self-closing door swing by default. If
you would like to reverse the door to open in the opposite direction, please follow the steps below:
1
. Carefully lay the unit on its back and remove the two (2) front leveling legs
2. Remove the two (2) hex head screws that connect the door hinges to the body on the bottom of the
unit
3. Remove the two (2) flathead screws that connect the hinge assembly to the bottom of the door
4. Remove the white hinge from the square rod
5. Slide the door towards the bottom until it is free of the top hinge
6. Unscrew the top hinge pin from the unit and reinstall on the left side
7. Flip the door so the handle is now on the right side
8. Push the door onto the top hinge piece
9. Reinstall the hinge assembly on the left side bottom of the door using the flathead screws
10. Push the white hinge onto the square rod at a position of 9 o’clock
11. Turn the white hinge clockwise until the holes line up with screws located on the bottom of the unit
12. Replace the hex head screws and front leveling legs
CA
UTION: After positioning the unit, you MUST allow it to stand upright for at least 2 hours to allow the
lubricant and refrigerant to drain back into the compressor and stabilize. Failure to do so may adversely affect
performance and the lifetime of this unit.
Stabilization Period - Prior to use, the unit shall be allowed to run and stabilize for at least twenty-four hours.
NOTE: Reversing the door will undo the self-closing function. Doors on units with -DL2B data logger
suffix are not reversible.
NOTE: Once the door has been reversed, the BOD Refrigerated Incubator sticker will be upside down.
You can remove and reapply to the preferred position. If you would like a replacement sticker, contact
our parts department at parts@summitappliance.com
