How to Install
Power On/O
1. Install the antennas as shown in the picture.
2. Use the cold shoe mount adapter to install
the CineView 2 SDI onto the camera or
camera cage.
3. Use an NP-F970/F750/F550 battery, DC or
USB-C source to power the CineView 2 SDI.
4. Connect the camera to the CineView 2 SDI
transmitter.
1. CineView 2 SDI has a group setting knob on each transmitter
and receiver. If the transmitter and receiver are set to the same
group, they will be paired and connected automatically; otherwise,
they will not be paired and connected.
2. If you want to connect multiple receivers (up to 4) to one
transmitter at the same time, simply set all receivers and
transmitters to the same group.
3. If you want to use more than one group for
monitoring under the same application, you need to
dierentiate the setting of each group.
PowerOn：
Pressthepower
on/obutton
Power Off：
Press and hold
the power on/o button for 2
seconds
Group Setting
Only 5V/3A USB-C power supported.
1. If you change the group settings after the product has been
powered on, a reboot is required for the changes to take eect.
2. After changing the group settings, you need to reconnect the
transmitter and receiver at close range, otherwise it may fail to pair
and connect.
LCD Display
Data Rate Setting
Connection Status:
① Wi-Fi signal status
② Connection status
③ Battery level
④ Current group
⑤ Current wireless channel
⑥ Input audio information
⑦ Input video information
① High Quality Mode (HQ)
② Normal Mode (NOR)
③ Speed Mode (SPD)
Ideal for applications with low
interference or within short
distance
Default setting
Ideal for applications with high interference or long distance.
Transmitter: the number of connected devices; “0” if none
connected.
Receiver: “1” when connected to the transmitter; otherwise “0”.
