8. Modes incl. running times
No. Mode Running time Lumen at front Lumen at rear
1 Steady 6 h. 8 8,5
2 Power 2 h. 50 24
3 Flow 11 h. 9 2-7,5
4 Pulse 27 h. 0-4 0-6
5 Flash 8 h. 0-28 0-40
6 Eco 40 h. 0 0-6
Note: When the brake is used, the running time is reduced by approx. 20% with
average use.
9. Remote controls
a) Remote Control Indicator Light, g. Info 4.
• Pairing: It is not necessary to pair the remote control with the helmet after purchase as
they are already paired. To pair additional remote controls, switch on the helmet, press
and hold the On/Off button and press and hold the L and R buttons on the remote control.
The helmet and remote control flash and are paired. Up to four remote controls can be
paired with one HYP-E helmet. Any number of HYP-E helmets can be paired with one
remote control.
• Mounting on the handlebar: Elastic rubber rings are supplied for attaching the remote
control to the handlebar. Select the rubber rings with the most suitable length so that the
remote control is rmly and securely attached to the handlebar.
• Charging: The remote control is powered by an integrated rechargeable battery. If the
battery is empty (LED continuously lit up red), it must be charged using the USB-C cable.
The charging socket is located on the underside of the remote control. Depending on use,
the remote control must be charged approximately every 2-4 months.
• Activating: Press the buttons (L: le, R: right) on the remote control to activate the
indicator light. It is therefore important to ensure correct le-right assignment during
installation. As long as the indicator light is switched on, a light ashes on the remote
control and an acoustic signal sounds as a reminder.
• Switching the acoustic signal on/off: The acoustic signal of the indicator light can be
switched o by holding the On/O button for 5 seconds when the system is switched o
until an acoustic signal sounds. Repeat the procedure to switch the acoustic signal back
on.
• Unpairing: Press and hold the L and R buttons on the remote control until the LEDs light
up orange, then press the le button twice and the right button twice. The LED lights up
red to conrm that the remote control and helmet are unpaired.
ATTENTION: The direction indicator function of the helmet is a supplementary feature and
does not replace legally required hand signals when turning. Make sure that you use the
correct side when activating the indicator light. Be sure to switch o the indicator light
aer turning by pressing the button again. If the indicator light is not switched o, it
will switch itself o automatically aer 40 seconds. The use of direction indicator lights
may be regulated by law in dierent countries.
Observe the laws of the respective country!
b) Remote Control Brake Light (OxiBrake), g. Info 9.
• Pairing: Before using for the rst time, the brake sensor must be paired with the helmet
(HYP-E and HYP-E ACE variants). Switch on the helmet lighting.
Press the On/O button for at least 6 seconds until the rear light ashes orange. Then press
the button on the brake sensor for at least 6 seconds until the status LED ashes red and
green. The rear light of the helmet lights up orange for a few seconds and then switches
o. The status LED of the brake sensor lights up red and green for a few seconds and then
switches o. The helmet and brake sensor are now paired.
• Mounting: Slide the silicone sleeve of the Remote Control Brake Light (OxiBrake) over the
brake lever on the handlebar. Adjust the Remote Control Brake Light (OxiBrake) to the
shape of the brake lever by bending it between 0° and 45°. ATTENTION! Do not bend the
Remote Control Brake Light (OxiBrake) multiple times. Bending too oen can damage the
material.
• Charging: Fully charge the battery before starting up the brake sensor.
The status LED ashes red during charging. When the status LED goes out, the battery is
fully charged. To check the battery level during use, press the button on the Remote
Control Brake Light (OxiBrake). The light lights up green when the battery is suciently
charged – and red when the charge level is low. When the battery charge is low, the light
also ashes red three times when the Remote Control Brake Light (OxiBrake) is no longer
being used. Depending on use, the remote control must be charged approximately every
2-4 weeks.
• Activating: The brake sensor switches on automatically when you touch the sensor
surface when operating the brake lever.
• Unpairing: Press the On/O button on the Remote Control Brake Light (OxiBrake) for at
least 6 seconds until it ashes red and green. Then press the button three times in quick
succession within 4 seconds.
ATTENTION: Before the start of every ride, make sure that the brake function of the brake
lever works without faults as it did in the original delivery state. Check the correct
position of the Remote Control Brake Light (OxiBrake) before the start of every ride.
10. Proper maintenance and care
• Check the helmet at regular intervals for visible defects.
• Never modify, alter or misuse the helmet or remove original parts, as this reduces the
protective effect of the helmet.
• Do not paint or stick anything on the helmet, as harmful substances can reduce its
stability and protective effect.
• The helmet must never be exposed to temperatures above 60°C (147°F), otherwise it may
lose its protective properties . Do not store behind glass, e.g. in a car (burning glass
eect), near heaters etc.
• If you suspect that the helmet has received a large impact, even if there is no visible
damage, please purchase a new helmet.
• Depending on the frequency of use and the specic operational conditions, a bicycle
helmet must be replaced 4 - 5 years aer the rst time it is used. In view of the
unavoidable material fatigue, the helmet must, however, be replaced at most 8 years
aer its production date even if it displays no clear visible or technical defects
• The helmet shell, adjustment wheel and removable inner pads can be cleaned by hand
(lukewarm water, soft cloths, solvent-free cleaner). This also applies to sun visors.
