3
FRONT & REAR PANELS
FRONT PANEL
q
POWER: Press the POWER button to power on the unit or set to standby mode. When power is disconnected, press this button again
while connected to the power to reset the system back to default factory settings. When the power is on, press and hold this button for (3)
seconds, the output monitor will show “USB Host Update MCU Firmware Start…”, then plug the USB (with the Firmware upgrade bin
le) to upgrade automatically. If monitor shows “Mass Storage Host Upgrade Running”, it means that the upgrade is proceeding, after
the upgrade is nished, the unit will reboot.
Note: If monitor did not show “Mass Storage Host Upgrade Running”, this means the rmware upgrade was not a success, please
power o the unit and try again.
REAR PANEL
q
HDMI IN: Connects with HDMI source equipment such as a DVD/Blueray player and/or PC/Laptop devices.
w
HDMI OUT A~D: Connects with HDMI TV/displays for output image display. It is suggested that the connection sequence should be
placed as the diagrams shows for TV wall set up.
e
SERVICE: This slot is for rmware update use only. Works with the power button.
r
CONTROL: Connects to an active network for Telnet control. Controlled with the “ANI-4K-VW” application for multi-device control.
t
RS-232: Connects from a PC/Laptop with D-Sub 9pin cables for RS-232 command control over the device.
Note: RS-232 control system is limited to a single Video Wall unit. Whereas Telnet can control multi-video Wall units.
y
DC 12V: Plug for the 12V DC power supply, which is included in the package, to the unit, then connect the adaptor to an AC outlet.
