Table of Parameters

3.2

30

signaling channel. This function can’t solve problems, when Easy Gate receives

DTMF, it influences sending direction only and it is active only when Easy Gate

originates the call.

Setting options: Analogue – DTMF transmission trough voice channel

without change (0)

Digital – DTMF is muted in voice channel and is

transmitted digitally (1)

Default setting: Analogue

Beep after dialing end Function No.: 103

Select a beep to signal the end of dialing (beginning of outgoing call

establishing).

Setting options: YES(1)/NO(0)

Default setting: YES

Signaling

Line reversal indication for call in progress Function No.:110

Select call in progress signaling by telephone line polarity reversal on FXS

interface. There is voltage of reversed polarity on the telephone line during the

whole call.

Setting options: YES(1)/NO(0)

Default setting: NO

Tariff pulse when call starts/ends Function No.: 111

Signaling of call start or end by tariff pulse.

Setting options: None (0)- EasyGate doesn't send tariff pulse as

signaling of callstart/end.

Call end (1) - EasyGate sends tariff pulse when call

ends.

Call start (2)- EasyGate sends tariff pulse when call

starts.

Call start and end (3) - EasyGate sends tariff pulse

when call starts and ends too.

Default setting: None

Tariff pulse frequency Function No.: 112

Tariff pulse frequency setting.

Setting options: 16 kHz (0) - EasyGate transmits 16 kHz tariff pulses

12 kHz (1)- EasyGate transmits 12 kHz tariff pulses

Default setting: 16 kHz
