Mounting

2.3

2.3 Mounting

External Antenna Connection

Screw the antenna enclosed into the SMA antenna connector.

Caution

n Tighten the antenna connector gently with your hand – never use

wrenches!

Note

n The antenna without cable has a sufficient gain for trouble-free operation

in normal conditions. If the signal is poor, if the interference occur or you

want to place your antenna separately from EasyGate , you can use an

antenna with an SMA-connector terminated cable. The antenna should be

mounted vertically.

n The Antenna shall be located within the same building as the main equipment.

n For antenna parameters see the “Technical Parameters”.

SIM Card Installation

Slot for SIM card is placed on the connector panel. Insert the SIM card to the slot with

contacts oriented to the front panel with LED. Make sure that the card is locked

properly.

Cautions

n Make sure that the provider’s SIM card is compatible with the GSM (UMTS)

network supported by your EasyGate version.

n Operator services and SIM card services, such as preferred networks, SMS

service centre, PIN protection etc. must be set in your mobile phone

before inserting your SIM card into EasyGate.

Power Supply Connection

EasyGate is fed with 10-16V DC. Where a source other than the included power supply

adapter is used, the voltage range and polarity have to be maintained. See technical

parameters.

EasyGate with battery option allows to support functionality in case of power failure.

For backup use four pieces of accumulators NiMh size AA. These accumulators are

usually not part of delivery. Put the accumulators to the battery holder on the bottom

side under the cover prior to installation. Polarity of accumulators is marked inside of

the battery space.
