The is designed for galvanic isolation of two devices 2N Helios IP Wiegand Isolator
®
with separate power supply and interconnected via the Wiegand bus. The 2N Helios
®
protects the interconnected devices against communication IP Wiegand Isolator
errors and/or damage.
Connection of the to a security system unit is a typical 2N Helios IP Card Reader
®
example of application.
Function:
The separates galvanically a two-wire Wiegand bus in 2N Helios IP Wiegand Isolator
®
one direction and a status LED signal in the other direction. The module is power
supplied from the Wiegand bus receiver side.
Specifications:
2-wire WIEGAND IN
2-wire WIEGAND OUT
LED IN switched against GND on WIEGAND OUT side
Open LED OUT switched against GND on WIEGAND IN side (up to 24 V / 50
mA)
5 to 16V / 10 mA power supply from Wiegand bus receiver side
500 V DC isolation strength
