Connection:
Connect the to the intercom as follows:2N Helios IP Security Relay
®
To the intercom active output (OUT1 or OUT2) , or
To the intercom relay output with a 12 V DC serial external power supply.
Connect the electric lock to the output as follows:2N Helios IP Security Relay
®
To the active 12 V / 700 mA DC output, or
To the relay output with a serial external power supply.
The device also supports a Departure button connected between the ‘PB’ and ‘-
HeliosIP’ terminals. Press the Departure button to activate the output for 5 seconds.
Status signalling:
Green LED Red LED Status
blinking off Operational mode
on off Activated output
blinking blinking Programming mode – waiting for initialisation
on blinking Error - wrong code received
Configuration:
Connect the to the properly set intercom switch 2N Helios IP Security Relay
®
output; refer to the Configuration Manual. Make sure that one LED at least on the
is on or blinking.2N Helios IP Security Relay
®
Press and hold the Reset button for 5 seconds to 2N Helios IP Security Relay
®
put the device in the programming mode (both the red and green LEDs are
blinking).
