2N TELEKOMUNIKACE a.s., www.2n.cz 58/110

1.

2.

Mounting Completion

Having connected all the wires, make sure that the bushings, if used, are

tightened properly and the RJ-45 connector is inserted in the PCB connector.

Replace the front cover carefully. Make sure that the connector is inserted

correctly and the wires inside the device leave enough space for the board if you

are installing a four-button board. Tighten the four screws thoroughly with the

wrench enclosed (Torx 20) to make the panel fit tightly to the metal chassis.

Caution

Properly installed intercom is waterproof. An incorrect mounting may

compromise the intercom watertightness. Water leakage may damage

the electronic part of the system.

Stainless steel screws are used for the assembly. 2N Helios IP Force

®

Other screws than stainless steel ones corrode soon and may

aesthetically deteriorate the surrounding environment!

Available Switches

Location Name Description

Basic Unit Relay 1 Passive relay switch : NO and NC contacts, up to 30 V / 1 A AC

/DC

Output 1 Active switch output: 9 up to 13 V DC depending on power

supply (PoE: 9 V; adaptor: power supply voltage minus 1 V), max

700 mA

Additional

Switch*

(Part No.

9151010)

Relay 2 Passive relay switch : NO and NC contacts, up to 30 V / 1 A AC

/DC

Output 2 Active switch output 9 up to 13 V DC depending on power :

supply (PoE: 9 V; adaptor: power supply voltage minus 1 V), max

700 mA

Relay 1

(Card

Reader),

Passive relay switch : NO and NC contacts, up to 30 V / 1 A AC

/DC
