Je bekijkt pagina 103 van 110
2N TELEKOMUNIKACE a.s., www.2n.cz 103/110
ISO/IEC 14443A
Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X, Ultralight,
Ultralight C
ISO/IEC 14443B
CEPAS, HID iCLASS
JIS X 6319
Felica
ISO/IEC 18092
SmartPhone with NFC/HCE support, since Android version 4.3
Wiegand Interface: Input/Output mode, located on RFID card reader module
Active switch output: 9 up to 13 V DC depending on power supply (PoE: 9 V;
adaptor: power supply voltage minus 1 V), max 700 mA
Passive relay switch: NO and NC contacts, up to 30 V / 1 A AC/DC
Additional switch
Optional: Includes also tamper switch
Active switch output: 9 up to 13 V DC depending on power supply (PoE: 9 V;
adaptor: power supply voltage minus 1 V), max 700 mA
Passive relay switch: NO and NC contacts, up to 30 V / 1 A AC/DC
Mechanical properties
Cover: Robust aluminium cast product, front panel: aluminium cast, fiberglass
FR4 (91511xxxR)
Working temperature: −40 °C to 55 °C
Working relative humidity: 10 % – 95 % (non-condensing)
Storing temperature: −40 °C to 70 °C
Dimensions
217 × 109 × 83 mm
242 × 136 × 83 mm incl. frame
Weight: netto max. 2 kg / brutto max. 2,5 kg
Covering level: IP65, IP69K (91511xxxW)
